FEATURES
•This terminal block is specially designed for AC control circuit;
•There are two fuses in the terminal block for short-circuit protection;
•With power display LED and fuse disconnecting warning LED;
•With 3 functions in one module, other modules for redistribution or filters need not be used.
The terminal station and shell are insulative, and if terminal stations and electric box shell need to be conductive, please connect separately.
SPECIFICATIONS
| ・型号Model | NHN-TPA08/6A NHN-TPA08/10A | NHN-TPA06/20ANHN-TPA06/20AS |
| •输入 额定电流Input Nominal operating current | 6A 10A | 20A |
| 额定电压Nominal coil voltage | AC220V | |
| 输入侧对应Corresponding input Devices | Into the line side AC power supply | |
| ・输出侧对应Corresponding output Devices | Load-side AC power simply | |
| •适合电线For wire | 2.5mm2 Following/AWG13 | 4mm2 Following/AWG13 |
